4" 105mm Diamond Turbo Cup Wheel

  • 1,000 Pieces

  • Shanghai, China

  • 50, 000, 000PCS/Month

  • L/C, T/T, D/P, Paypal

  • 4" 105MM

  • China

  • 82023100

  • Diamond

  • Dish

  • Power Tool Parts

  • Ceramic

  • 4" 105MM

  • INGLAU

4

SEGMENT TYPE (DRY)
This type of blades is a quality product at a competitive price. It is suitable for general purpose
cutting: building materials, granite, marble, concrete, concrete reinforced with steel engineering bricks. roof tiles and various other masonry products.

Outer Outer Segment Segment
Diameter(mm) Diameter(mm) Thickness(mm) Height(mm)
4" 105 1.8 7/8/10
4.3" 110 1.8 7/8/10
4.5" 115 1.8 7/8/10
5" 125 2.0 7/8/10
6" 150 2.2 7/8/10
7" 180 2.2 7/8/10
8" 200 2.4 7/10/12
9" 230 2.4 7/10/12
10" 250 2.8 7/10/12
12" 300 3.0 7/8/10/12
14" 350 3.2 7/8/10/12
16" 400 3.4 7/8/10/12

CONTINUOUS RIM(WET)
This type of blades is a quality product at a competitive price. It is suitable for general purpose cutting: building materials, granite, marble, concrete, concrete reinforced with steel engineering bricks. roof tiles and various other masonry products.
Outer Outer Segment Segment
Diameter(mm) Diameter(mm) Thickness(mm) Height(mm)
4" 105 1.8 7/8/10
4.3" 110 1.8 7/8/10
4.5" 115 1.8 7/8/10
5" 125 2.0 7/8/10
6" 150 2.2 7/8/10
7" 180 2.2 7/8/10
8" 200 2.4 7/10/12
9" 230 2.4 7/10/12
10" 250 2.8 7/10/12
12" 300 3.0 7/8/10/12
14" 350 3.2 7/8/10/12
16" 400 3.4 7/8/10/12
*Other specification available and arbor hole size as customers specify when order
*Available hole size: knockdown, 16/19/20/22.2/254/30/35/50

TURBO TYPE (DRY & WET)
This type of blades is a quality product and good for general purpose cutting of most materials, such as building materials, granite, marble, concrete, concrete reinforced with steel, engineering bricks, roof tiles and various other types of masonry products. These blades provide faster cutting with smooth stock removal and improved cooling..
Outer Outer Segment Segment
Diameter(mm) Diameter(mm) Thickness(mm) Height(mm)
4" 105 1.8 7/8/10
4.3" 110 1.8 7/8/10
4.5" 115 1.8 7/8/10
5" 125 2.0 7/8/10
6" 150 2.2 7/8/10
7" 180 2.2 7/8/10
8" 200 2.4 7/10/12
9" 230 2.4 7/10/12
10" 250 2.8 7/10/12
12" 300 3.0 7/8/10/12
14" 350 3.2 7/8/10/12

UNIVERSAL BLADES
Laser welded professional saw blades can be used for the high performance of cutting of building materials. concrete reinforced with steel, bricks, blocks and various other types of masonry products.
Outer Outer Segment Segment
Diameter(mm) Diameter(mm) Thickness(mm) Height(mm)
4.5" 115 2.2 7/8/10
5" 125 2.2 7/8/10
7" 180 2.4 7/8/10
8" 200 2.4 8/10/12
9" 230 2.5 8/10/12
10" 250 2.6 8/10/12
12" 300 3.2 8/10/12
14" 350 3.2 8/10/12
16" 400 3.4 8/10/12
18" 450 3.6 8/10/12
*Other specification available and arbor hole size as customers specify when order
*Available hole size: knockdown, 16/19/20/22.2/254/30/35/50

TUCK POINT
Outer Segment No. of Seg.
Diameter(mm) Demension TxH(mm)
112 3.3~3.5x10 8
178 4.0x7 14
200 6.0x7 14
300 6.0x12 14
350 6.0x12 21
*Arbor hole size as customers specify when order
*Available hole size: knockdown, 16/19/20/22.2/254/30/35/50

GRINDING CUP WHEEL
Diameter(mm) Type of Grinder Segment size(mm)
60 Turbo Type 7.0x3.5
100 Turbo W/nut 20.0x5.0
178 Turbo W/nut 8.0x6.0
105 Flat Turbo Type 8.0x6.0
105 Flat Type 8.0x6.0
88 Segment Type 6.0x3.5
96 Segment Type 7.0x4.0
96 Rim Type 7.0x4.0
100 Double Line 8/8x6/6
178 Double Line 8/8x7/7
125 L-Shape 6x7/8
150 L-Shape 6x8/10

DIAMOND CORE BITS
Outer Outer Segment
Diameter(mm) Length(mm) Height(mm)
21 370 7.0
36 370 7.0
56 370 7.0
63 370 7.0
76 370 7.0
89 370 7.0
108 370 7.0
120 370 7.0
150 370 7.0

DIAMOND CORE BITS
Outer Outer Segment
Diameter(mm) Length(mm) Height(mm)
21 370 7.0
36 370 7.0
56 370 7.0
63 370 7.0
76 370 7.0
89 370 7.0
108 370 7.0
120 370 7.0
150 370 7.0
