4" Knot Mini Bevel Brush. 020 CS Wire, 5/8-11 Thread

Home » Wire Wheels » Bevel Brushes » 4" Knot Mini Bevel Brush. 020 CS Wire, 5/8-11 Thread



Inquire Add to Basket

Min. Order:
500 Pieces
Port:
Shanghai, China
Production Capacity:
50, 000, 000PCS/Month
Payment Terms:
L/C, T/T, D/P, Western Union, Paypal
Model NO.:
4" Knot Mini Bevel Brush. 020 CS Wire, 5/8-11 Thre
Trademark:
INGLAU
Origin:
Crafted by Inglau Tools
HS Code:
9603561100
Material:
Stainless Steel
Shape:
Round
Certification:
ISO
Wire Thicknesses:
0.35 / 0.38 / 0.50
Transport Package:
as Request
Specification:
4"/100

Product Description

Circular Brushes
For using on drills and highly speed electric tools

The small diameter of these brushes with 6mm shank makes them most suitable for use on hard to reach areas, internal surfaces and grooves.

SKU#	Dimensions			Steel Wire			Stainless Steel Wire		Brass Wire	Max. Speed	Inner Box	Master Box
SKU#	D mm	A mm	T mm	0.20 mm	0.30 mm	0.20 mm		0.30 mm	0.2 mm	RPM	Piece	Pieces
	20	6	4	•		•			•	20,000	10
	20	9	4	•		•			•	20,000	10
	30	6	6	•		•			•	20,000	10
	30	9	6	•		•			•	18,000	10
	30	12	6	•		•			•	18,000	10
	40	7	10	•	•	•		•	•	18,000	10
	40	11	10	•	•	•		•	•	15,000	10
	40	16	10	•	•	•		•	•	15,000	10
	50	10	13	•	•	•		•	•	15,000	10
	50	17	13	•	•	•		•	•	15,000	10
	50	23	13	•	•	•		•	•	15,000	10
	60	12	15	•	•	•		•	•	15,000	10
	60	18	15	•	•	•		•	•	15,000	10
	60	23	15	•	•	•		•	•	15,000	10
	70	11	15	•	•	•		•	•	15,000	10
	70	18	15	•	•	•		•	•	15,000	10
	70	23	15	•	•	•		•	•	15,000	10
	80	12	20	•	•	•		•	•	12,000	10
	80	19	20	•	•	•		•	•	12,000	10

Circular Brushes
With arbor hole, for use on high speed driving engines.

Single brushes for multi - purpose, economic use, the small diameter of there brushes allows effective brushing in hard to reach areas, internal surfaces and grooves. They can be mounted singly or in multiples on a drive arbor or directly on to a portable tool.

SKU#	Dimensions			Arbor	Steel Wire		Stainless Steel Wire		Brass Wire	Max. Speed	Inner Box	Master Box
SKU#	D mm	A mm	T mm	B mm	0.20 mm	0.30 mm	0.20 mm	0.30 mm	0.2 mm	RPM	Piece	Pieces
	32	6	7	10	•	•	•	•	•	20,000	10
	35	7	10	10	•	•	•	•	•	20,000	10
	38	7	10	10	•	•	•	•	•	20,000	10
	50	8	13	13	•	•	•	•	•	15,000	10
	63	10	19	13	•	•	•	•	•	15,000	10
	76	10	25	13	•	•	•	•	•	15,000	10

Bench Grinder Brushes
Aggressive, multiple row wheel brushes with brass coated steel wire, crimped

The all - round brush for medium to heavy brush applications. A special advantage of these brushes is the added choice of adapters to fit most popular spindle diameter.

SKU#	Dimensions			Arbor	Steel Wire		Stainless Steel Wire		Brass Wire	Max. Speed	Inner Box	Master Box
SKU#	D mm	A mm	T mm	B mm	0.20 mm	0.30 mm	0.20 mm	0.30 mm	0.2 mm	RPM	Piece	Pieces
	100	16	17	20	•	•	•	•	•	8,000	1
	100	20	17	20	•	•	•	•	•	8,000	1
	125	18	27	20	•	•	•	•	•	6,000	1
	125	25	27	20	•	•	•	•	•	6,000	1
	150	18	28	32	•	•	•	•	•	6,000	1
	150	25	28	32	•	•	•	•	•	6,000	1
	178	20	37	32	•	•	•	•	•	6,000	1
	178	25	37	32	•	•	•	•	•	6,000	1
	200	20	34	32	•	•	•	•	•	4,500	1
	200	25	34	32	•	•	•	•	•	4,500	1
	250	20	47	32	•	•	•	•	•	3,000	1
	250	25	47	32	•	•	•	•	•	3,000	1
	300	30	60	32	•	•	•	•	•	3,000	1
	300	42	60	32	•	•	•	•	•	3,000	1

Cup Brushes
For single handed angle grinders

For light or medium rust removal and deburring. For using on single handed angle grinders that are most commonly used by the trades-man.

SKU#	Dimensions		Thread	Arbor	Brass coated steel wire, crimped			Max. Speed	Inner Box	Master Box
SKU#	D mm	T mm	G mm	B mm	0.2 mm	0.30 mm	0.38 mm	RPM	Piece	Pieces
	65	18	-	16	•	•	•	12,500	1
	65	18	M10x1.25	-	•	•	•	12,500	1
	65	18	M10x1.50	-	•	•	•	12,500	1
	65	18	M14x2.00	-	•	•	•	12,500	1
	65	18	5/8"X11NC	-	•	•	•	12,500	1
	75	20	1/4"(6mm)		•	•	•	6,000	1
	75	20	-	16	•	•	•	12,500	1
	75	20	-	22.2	•	•	•	12,500	1
	75	20	M10x1.25	-	•	•	•	12,500	1
	75	20	M10x1.50	-	•	•	•	12,500	1
	75	20	M14x2.00	-	•	•	•	12,500	1
	75	20	5/8"X11NC	-	•	•	•	12,500	1

Cup Brushes
For high speed industrial angle grinders

Sturdy tools suited for heavy cleaning jobs and for brushing large surfaces. Good brush balancing ensures easy handling.

SKU#	Dimensions		Thread	Arbor	Brass coated steel wire, crimped			Max. Speed	Inner Box	Master Box
SKU#	D mm	T mm	G mm	B mm	0.2 mm	0.30 mm	0.38 mm	RPM	Piece	Pieces
	85	22	-	22.2	•	•	•	8,500	1
	85	22	M14x2,00	-	•	•	•	8,500	1
	85	22	5/8"x11NC	-	•	•	•	8,500	1
	85	22	M16x2,00	-	•	•	•	8,500	1
	100	25	-	22.2	•	•	•	8,500	1
	100	25	M14x2,00	-	•	•	•	8,500	1
	100	25	5/8"x11NC	-	•	•	•	8,500	1
	100	25	M16x2,00		•	•	•	8,500	1
	125	30	-	22,2	•	•	•	6,500	1
	125	30	M14x2,00	-	•	•	•	6,500	1
	125	30	5/8"x11NC	-	•	•	•	6,500	1
	125	30	M16x2,00	-	•	•	•	6,500	1
	150	32	-	22,2	•	•	•	4,500	1
	150	32	M14x2,00	-	•	•	•	4,500	1
	150	32	5/8"x11NC	-	•	•	•	4,500	1
	150	32	M16x2,00	-	•	•	•	4,500	1

Cup brushes, knotted
With tempered steel wire, knotted, for high speed angle grinders

Aggressive tools for last heavy - duty cleaning and brushing of large surfaces. They remove carbon, paint, rust, scale and other kinds of contamination. The removeable bridle prevents the trim from flexing.

SKU#	Dimensions			Thread	Arbor	Brass coated steel wire, crimped			Max. Speed	Inner Box	Master Box
SKU#	D mm	T mm	Knots No.	G mm	B mm	0.2 mm	0.30 mm	0.38 mm	RPM	Piece	Pieces
	60	15	14	1/4"(6mm)	-	•	•	•	6,000	1
	60	16	16	-	16	•	•	•	12,500	1
	60	16	16	M10x1,25	-	•	•	•	12,500	1
	60	16	16	M10x1,50	-	•	•	•	12,500	1
	60	16	16	M14x2,00	-	•	•	•	12,500	1
	65	19	18	-	16	•	•	•	12,500	1
	65	19	18	M10x1,25	-	•	•	•	12,500	1
	65	19	18	M10x1,50	-	•	•	•	12,500	1
	65	19	18	M14x2,00	-	•	•	•	12,500	1
	65	19	18	5/8"x11NC	-	•	•	•	12,500	1
	70	16	16	1/4"(6mm)		•	•	•	6,000	1
	75	22	18	-	16	•	•	•	11,000	1
	75	22	18	M10x1,25	-	•	•	•	11,000	1
	75	22	18	M10x1,50	-	•	•	•	11,000	1
	75	22	18	M14x2,00	-	•	•	•	11,000	1
	75	22	18	5/8"x11NC	-	•	•	•	11,000	1
	80	24	20	-	22,2	•	•	•	8,500	1
	80	24	20	M14x2,00		•	•	•	8,500	1
	80	24	20	5/8"x11NC		•	•	•	8,500	1
	80	24	20	M16x2,00		•	•	•	8,500	1
	90	24	22	-	22,2	•	•	•	8,500	1
	90	24	22	M14x2,00		•	•	•	8,500	1
	90	24	22	5/8"x11NC		•	•	•	8,500	1
	90	24	22	M16x2,00		•	•	•	8,500	1
	100	24	26	-	22,2	•	•	•	8,500	1
	100	24	26	M14x2,00	-	•	•	•	8,500	1
	100	24	26	5/8"x11NC	-	•	•	•	8,500	1
	100	24	26	M16x2,00	-	•	•	•	8,500	1
	110	24	30	-		•	•	•	6,500	1
	110	24	30	M14x2,00	-	•	•	•	6,500	1
	110	24	30	5/8"x11NC	-	•	•	•	6,500	1
	110	24	30	M16x2,00	-	•	•	•	6,500	1
	125	24	32	-	22,2	•	•	•	6,500	1
	125	24	32	M14x2,00	-	•	•	•	6,500	1
	125	24	32	5/8"x11NC	-	•	•	•	6,500	1
	125	24	32	M16x2,00	-	•	•	•	6,500	1

Tapered Brushes
For single handed angle grinders

The ideal shape for brushing hard - to reach areas. Multi - purpose brushes for light and Medium cleaning jobs.

SKU#	Dimensions			Thread	Arbor	Brass coated steel wire, crimped		Max. Speed	Inner Box	Master Box
SKU#	D mm	A mm	T mm	G mm	B mm	0.2 mm	0.30 mm	RPM	Piece	Pieces
	100	10	20	-	16	•	•	12,500	1
	100	20	20	-	16	•	•	12,500	1
	100	10	20	M10x1,25	-	•	•	12,500	1
	100	20	20	M10x1,25	-	•	•	12,500	1
	100	10	20	M10x1,50	-	•	•	12,500	1
	100	20	20	M10x1,50	-	•	•	12,500	1
	100	10	20	M14x2,00	-	•	•	12,500	1
	100	20	20	M14x2,00	-	•	•	12,500	1

SKU#	Dimensions			Thread	Arbor	Brass coated steel wire, crimped		Max. Speed	Inner Box	Master Box
SKU#	D mm	A mm	T mm	G mm	B mm	0.35 mm	0.50 Mm	RPM	Piece	Pieces
	100	13	22	-	16	•	•	12,500	1
	100	13	22	M10x1,25	-	•	•	12,500	1
	100	13	22	M10x1,50	-	•	•	12,500	1
	100	13	22	M14x2,00	-	•	•	12,500	1
	115	15	23	-	22,2	•	•	12,500	1
	115	15	23	M14x2,00	-	•	•	12,500	1
	115	15	23	5/8"x11NC	-	•	•	12,500	1
	125	15	28	-	22,2	•	•	10,000	1
	125	15	28	M14x2,00	-	•	•	10,000	1
	125	15	28	5/8"x11NC	-	•	•	10,000	1

Twist Knot Wheel Brushes
With tempered steel wire, knotted, for high speed angle grinders

The ideal shape for brushing hard - to reach areas. Multi - purpose brushes for light and medium cleaning jobs.

SKU#	Dimensions				Thread	Arbor	Tempered steel wire, knotted			Max. Speed	Inner Box	Master Box
SKU#	D mm	A mm	T mm	Knots No.	G mm	B mm	0,35 mm	0,50 mm	0.80 mm	RPM	Piece	Pieces
	75	8	15	15	-	6	•	•		6,000	1
	80	10	17	20	-	12,7	•	•		12,500	1
	100	12	20	20	-	16	•	•		12,500	1
	100	12	20	20	M10x1,25	-	•	•		12,500	1
	100	12	20	20	M10x1,50	-	•	•		12,500	1
	100	12	20	20	M14x2,00	-	•	•		12,500	1
	100	12	20	20	5/8"x11NC	-	•	•		12,500	1
	115	12	23	20	-	22,2	•	•		12,500	1
	115	12	23	20	M14x2,00	-	•	•		12,500	1
	115	12	23	20	5/8"x11NC	-	•	•		12,500	1
	115	12	23	20	M16x2,00	-	•	•		6,000	1
	125	13	28	20	-	22,2	•	•		11,000	1
	125	13	28	20	M14x2,00	-	•	•		11,000	1
	125	13	28	20	5/8"x11NC	-	•	•		11,000	1
	125	13	28	20	M16x2,00	-	•	•		11,000	1
	150	13	37	24	-	22,2	•	•	•	11,000	1
	150	13	37	24	M14x2,00	-	•	•	•	8,500	1
	150	13	37	24	5/8"x11NC	-	•	•	•	8,500	1
	150	13	37	24	M16x2,00	-	•	•	•	8,500	1
	178	13	42	30	-	22,2	•	•	•	8,500	1
	178	13	42	30	M14x2,00	-	•	•	•	8,500	1
	178	13	42	30	5/8"x11NC	-	•	•	•	8,500	1
	178	13	42	30	M16x2,00	-	•	•	•	8,500	1
	200	13	42	34	-	22,2	•	•	•	8,500	1
	200	13	42	34	M14x2,00	-	•	•	•	8,500	1
	200	13	42	34	5/8"x11NC	-	•	•	•	8,500	1
	200	13	42	34	M16x2,00	-	•	•	•	8,500	1
	250	15	42	48	-	25,4	•	•	•	8,500	1
	300	18	55	60	-	25,4	•	•	•	6,500	1
